HONOR MagicBook X 14 2022 Specification - System, graphics, processor

Check the latest HONOR MagicBook X 15 2022 for HONOR MagicBook X Series. Learn More

Color

Space Gray

Operating System

Windows 11 Home

Appearance

Material

Aluminium alloy

Maximum Opening Angle

Approx. 180 degrees

Dimensions

Length

322.5mm

Width

214.8mm

Thickness

15.9mm

Narrow Bezel

4.8mm(left/right/top side)

Weight

Approx. 1.38Kg

Display

Size

14 inches

Screen-To-Body Ratio

84%

Resolution

1920x1080

PPI

157 PPI

Color Gamut

45% NTSC(Typical)

Contrast Ratio

800 : 1(Typical)

Aspect Ratio

16:9

Screen Type

IPS

Viewing Angle

178 degrees(Typical)

Brightness

250nits(Typical)

Eye Comfort Mode

Support (TÜV Rheinland Low Blue Light Certification)

Support (TÜV Rheinland Flicker Free Certification)

Processor

CPU Model

Intel® Core™ i5-1135G7

CPU Frequency

Base 2.4GHz; Up to 4.2GHz

CPU Cores

4 cores (i5)

Graphics

Intel® Iris® Xe Graphics (i5)

Storage

512GB (i5)

Memory

Memory Capacity

8GB

Memory Type

DDR4 2666MHz

Memory Channels

Dual Channel

Connectivity

Wi-Fi

IEEE 802.11a/b/g/n/ac/ax,160MHz

Wi-Fi Frequency Bands

2.4GHz and 5GHz

Bluetooth Standard

Bluetooth 5.1

HONOR Magic-link

Support

Battery

Battery Capacity

56Wh(Rated capacity)

Battery Type

Li-polymer

Ports

AC Jack

USB-C(on the left)

USB-C Port

USB-C*1

USB-A Port

Left side: USB3.2 Gen1 *1

Right side: USB 2.0 *1

HDMI

Audio Port

3.5mm headset and microphone 2-in-1 jack x 1, support both OMTP and CTIA

Keyboard and Touchpad

Keyboard Type

Full-size backlit keyboard

Actuation Distance

1.3mm

Touchpad

Support 4-point multi-touch

Touchpad Size

119.2mm*62.5mm

Power Button

Fingerprint power button ( with touch fingerprint sensor )

Camera

720P HD Recessed camera

Video Recording / Video Chat

Audio

speaker*2

Immersive surround sound

Microphone*2

Featured Applications

HONOR Magic-link/PC Manager

In The Box

1) PC *1

2) USB-C Power Adapter *1

3) Charger cable(Type C) *1

4) Quick Sart Guide *1

5) Warranty card *1
